Fabricar cable Midi.

chinchi
#1 por chinchi el 10/10/2013
Guenasss
Pues eso, estoy pensando hacerme yo un cable midi de 10m o mas para mi pedal sanpera.
Los conectores sin problemas pero estaba pensado usar como cable un simple cable de red de 8 hilos (que consigo los m que quiera), pero tengo la duda si sera buen cable. Creo que con 0.5mm hay de sobra pero no se si por su longitud podria dar algun problema. Que yo sepa o crea este pedal solo sirve de "interruptor" para que el ampli realice la seleccion, asi que problemas de impedancias o caidas no creo que de, pero... esto es seguro?
Por otro lado que yo recuerde el cable de red no lleva malla, no? por lo que mi cable no iria apantallado ni los conectores tierra. Daria ruidos?

Alguien me puede decir algo?
Un saludo.
Subir
OFERTASVer todas
  • Harley Benton DNAfx GiT
    139 €
    Ver oferta
  • Taylor 214ce-SB DLX
    1.198 €
    Ver oferta
  • Harley Benton TE-52 NA Vintage Series
    169 €
    Ver oferta
Andrés Vargas - chempi
#2 por Andrés Vargas - chempi el 10/10/2013
El maximo de longitud para el cable midi es de 15 m según la especificación MIDI, pero usando cables de muy buena calidad, el limite para cables normales sería de alrededor de 6 m.

Alguien escribió:
MIDI is an asynchronous serial interface. The baud rate is 31.25 Kbaud (+/- 1%). There is 1 start bit, 8 data bits, and 1 stop bit (ie, 10 bits total), for a period of 320 microseconds per serial byte.
The MIDI circuit is current loop, 5 mA. Logic 0 is current ON. One output drives one (and only one) input. To avoid grounding loops and subsequent data errors, the input is opto-isolated. It requires less than 5 mA to turn on. The Sharp PC-900 and HP 6N138 optoisolators are satisfactory devices. Rise and fall time for the optoisolator should be less than 2 microseconds.

The standard connector used for MIDI is a 5 pin DIN. Separate jacks (and cable runs) are used for input and output, clearly marked on a given device (ie, the MIDI IN and OUT are two separate DIN female panel mount jacks). 50 feet is the recommended maximum cable length. Cables are shielded twisted pair, with the shield connecting pin 2 at both ends. The pair is pins 4 and 5. Pins 1 and 3 are not used, and should be left unconnected.

A device may also be equipped with a MIDI THRU jack which is used to pass the MIDI IN signal to another device. The MIDI THRU transmission may not be performed correctly due to the delay time (caused by the response time of the opto-isolator) between the rising and falling edges of the square wave. These timing errors will tend to add in the "wrong direction" as more devices are daisy-chained to other device's MIDI THRU jacks. The result is that there is a limit to the number of devices that can be daisy-chained.


http://home.roadrunner.com/~jgglatt/tech/midispec.htm

El cable debe ser the par enrollado aislado ( Cables are shielded twisted pair, with the shield connecting pin 2 at both ends. The pair is pins 4 and 5. Pins 1 and 3 are not used, and should be left unconnected).
Subir
chinchi
#3 por chinchi el 11/10/2013
Gracias por contestar Chempi, pero esas especificaciones creo son un cable midi "MIDI", osea, para comunicacion de señal.
Yo creo que el cable del pedal Sanpera de Peavey no lleva señal. A mi entender el pedal Sanpera digamos que es como un teclado, tan solo hace de interruptor/es para que el software del amplificador reciba las ordenes de cambio de efecto y segun que interruptor se accione lo realice.

Usa un cable midi mas bien por el numero de pines que lleva, 8 en total y todos conectados, pero realmente no lleva señal. Al menos eso creo.
Lo unico es que como no lo tengo claro tengo esa duda, que el cable deba llevar algun tipo de especificacion, al menos para evitar parasitos o yo que se.

El cable largo de Peavey ya es dificil de encontrar y valen un porron mientras que si puedo hacerlo tal como digo me sale ya ves, tirado.
No se si probar y listo, tampoco pierdo mucho.
Subir
Andrés Vargas - chempi
#4 por Andrés Vargas - chempi el 11/10/2013
Buscando en internet vi que el sanpera si manda comandos midi, no son simples señales de interruptores, y adicionalmente el sanpera recibe la alimentación via el mismo cable MIDI.

http://e-lectronics.net/img/Sanpera/index.html

MIDI board

MIDI interface is the only way how to foot-control your Vypyr (with Sanpera I & II foot controllers), access looper function and upgrade internal firmware. Through MIDI you can fully control all settings, access all 412 internal banks/presets, use volume/wah/pitch/ gas pedals. By small modification of board, you can even gain from MIDI out and get the feedback from the amp.
http://drieg.com/

Hay gente que utiliza controladores MIDI como el fcb1010 para controlar el peavey vypyr. Saludos
Subir
chinchi
#5 por chinchi el 12/10/2013
Que mal me llevo yo con el ingles juer... :p
Bueno esta, pues seguramente probare a hacerlo, si no funciona o hace ruidos sera cuestion de ahorrar para uno en condiciones.
El caso es que estoy ahorrando para un 6505 y si no es por una cosa es por otra, asi no se puede!! :(

Muchas gracias por tu tiempo Chempi. Al menos ya se de que va el tema.
Un saludo ;)
Subir
